BILOBA 8910 Swing Door Hinge Glass Door Hinge for Glass Wall 8-13.52 mm Hydraulic Band with Zero Position Adjustment, Matte Stainless Steel

Self-closing hydraulic swing door hinge with central attachment (wall glass) for living room and contract swing doors made of glass, hydraulic band for use with wall-glass combinations with adjustment of the door closing speed with zero position setting, lock at + 90° and - 90° automatic closing from + 80° and - 80° (the angle for the beginning of self-closing. can depdepdepdepdepdepinfluencing factors and the door format vary by +/- 5 degrees in the usual fields of application) can also be used for stop doors. Forced opening over 95° could pry the door, we recommend installing a door stopper. Locking point: 90° wing width (mm): max. 1000 factory number: 891013 mounting type: glass wall glass thickness (mm): 8 - 13.52 load capacity (kg): 100 design: double-sided mounting plate with mounting holes 4 x diameter 5 mm countersunk holes type: Biloba 8910 material: matt stainless steel content specification (ST): 1

• Hydraulic swing door band: glass door hinge with efficient self-closing hydraulic function for glass wall combinations - ideal for living room and contract swing doors made of glass
• Adjustable: door hinge with adjustable door closing speed and zero position adjustment - for precise control and locking at +90° and -90°, with automatic closing from ±80°
• Use: suitable for swing and stop doors – it is recommended to install a door stopper to prevent forced opening above 95° as the door could leverage
• Specifications: load capacity: 100 kg. Blade width: max. 1000 mm. Locking point: 90°. Factory number: 891013. Mounting type: glass wall
• Box contents: 1 x pendulum glass door hinge on both sides with mounting holes, 4 x diameter 5 mm countersunk holes
